The slitting line is used to unwind, slit, and wind the metal coil into a coil with the required width. Suitable for processing cold-rolled and hot-rolled carbon steel, silicon steel, tinplate, stainless steel and various metal materials after surface coating.

For users with high requirements, you can choose EPC automatic edge alignment or centering cutting, which is convenient for feeding, improves work efficiency, and improves cutting accuracy and protects the sheet. EPC automatic edge control can also be selected to ensure the neatness of the winding, especially suitable for wide material winding.

The production line is mainly composed of loading trolley, uncoiler, traction leveling machine, shearing machine, slitting machine, scrap winder, tension mechanism, winder, unloading device, etc.

·High degree of automation, simple and reliable operation.

·The slitting machine can be interchanged, and the work efficiency is high.

Fast production line speed, self-matching unit speed

The main parameters are as follows

1. Straightness: ≤1 mm/1M (cold-rolled stainless steel plate with a thickness of 1.0 or less, not counted within 12 meters of the plate head and tail)

2. Width tolerance: ±0.05mm

3. Shearing burr: ≤ 3% of the thickness of the strip (the thickness of the new knife is less than 1.0), the minimum is 0.02;

4. The runout of the shoulder of the knife shaft ≤0.005mm;

5. The axial movement of the cutter shaft ≤0.005mm;
